select | Inquiry | Designation | Principal dimensions(mm) | Basic load ratings(KN) | Basic load ratings(kgf) | Limiting Speed (rpm) | Distance of action point | Installation dimensions(mm) | Weight | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
d | D | B | r(min) | Cr | Cor | Cr | Cor | Grease | Oil | a0(mm) | da(min) | Da(max) | ra(max) | (kg) | |||
QJ1016 | 80 | 125 | 22 | 1.1 | 77000 | 167000 | 7850 | 17000 | 3800 | 5300 | 71.8 | 87 | 118 | 1 | 1.05 | ||
QJ1017 | 85 | 130 | 22 | 1.1 | 79000 | 176000 | 8050 | 18000 | 3800 | 5000 | 75.3 | 92 | 123 | 1 | 1.1 | ||
QJ1018 | 90 | 140 | 24 | 1.5 | 94000 | 208000 | 9600 | 21200 | 3400 | 4800 | 80.5 | 99 | 131 | 1.5 | 1.45 | ||
QJ1019 | 95 | 145 | 24 | 1.5 | 96500 | 220000 | 9800 | 22500 | 3400 | 4500 | 84 | 104 | 136 | 1.5 | 1.5 | ||
